3mm 6mm Stainless Steel Laser Cutting Machine Fast Cam For Craft Gifts / Tube Fittings

Product Categories

Shanghai ProMega Trading Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

3mm 6mm Stainless Steel Laser Cutting Machine Fast Cam For Craft Gifts / Tube Fittings

Brand Name : PM

Model Number : HS-M3015B

Certification : CE, ISO

Place of Origin : China

MOQ : standard wood case

Price : USD 100,000 to 200,000 per set

Payment Terms : L/C, T/T

Supply Ability : one set per month

Delivery Time : Within 20 days

Packaging Details : standard wood case

Application : Laser Cutting

Applicable Material : Acrylic,Crytal,Glass,Leather,MDF,Metal,Paper,Plastic,Plexiglax,Plywood,Wood

Control Software : Fast CAM

After-sales Service : Engineers available oversea

Cutting thickness : 6mm Mild Steel/ Stainless Steel

Graphic Fromat supported : AI,BMP,DST,DWG,DXF,DXP,LAS,PLT

Laser source : Germany IPG Fiber Laser

Power supply : 380V 50HZ

Contact Now

Laser cutting machine stainless steel for 6mm Mild Steel ,3mm Stainless Steel HS-M3015B

Technical Parameters:

Product name	Laser cutting machine stainless steel for 6mm Mild Steel ,3mm Stainless Steel HS-M3015B
Working table(mm)	1500*3000
Laser power(W)	500
Weight(kg)	5000
Table load(kg)	500
Machine body size(mm)	448233072740
Max.Acceleration Speed	0.3G
Transmitting System	Movable gantry, single driving
Max running speed	60m/min
Positioning Accuracy	0.05mm
Working Power Supply	380V±10% 50HZ
X/Y Positioning Accuracy	±0.05mm
Power Phases	3
Running Temperature	0°C-40°C
Max Acceleration	0.3G
Formats	DXF,AI,DST
Applied Materials	Thin mild steel, stainless steel and other kinds of metallic sheets(non-ferrous metal not suggested)

Cutting samples:

Features:

1. 600°C heat treatment, 24 hours cooling in the oven, 8 meters gantry milling, accurate CO2
protection welding, to make sure 20 years usage without deformation.

2. Use the collimator to install and adjust guide rail, precision: ≤0.01mm

3. Taiwan precise ball screw and linear guide rail, highest speed up to 60 meters/ minute and
accelerated speed up to 0.5g.

4. Japanese original imported servo system ensures the high precision of transmitting.

5. German speed reducer to enhance the accelerated speed and torsional force.

3mm 6mm Stainless Steel Laser Cutting Machine Fast Cam For Craft Gifts / Tube Fittings

Remotely control:

Package and load:

Applied industry:

1. sheet metal processing	√
2. aviation	√
3. aerospace	√
4. electronics	√
5. electrical appliances	√
6. tube fittings	√
7. automobile	√
8. food machinery	√
9. textile machinery	√
10. engineering machinery	√
11. precision parts	√
12. ships	√
13. metallurgy equipment	√
14. elevators	√
15. household appliances	√
16. craft gifts	√
17. tool processing	√
18. decoration	√
19. advertising	√
20.metal processing and other manufacturing industries	√
